| Inspection speed |
최대 2m/s (6ft/s) |
| Excitation Frequencies |
Single frequency |
| Frequency range |
1KHz ~ 1MHz |
Probe balancing
|
True menu balancing type |
| Supported probes |
Differential or absolute
bobbin, Hall effect sensor |
| Analog filter |
Low-pass, high-pass |
| Encoders |
2 quadrature encoders
input (option) |
| Inspect method |
Still - Contact |
| Eddy type |
Pulse generator |
| Sensing method |
differential or absolute |
| Comparator |
non or be |
| Check Limit |
1 step 1point |
| Power |
AC 220V, DC 12V (option) |
|
|
※
The manufacture
specification can
be changed according
to a Test Sample.
|
|
|
|
|
