The ultrasonic Pulse/Echo principle uses the round-trip
travel time of a sound wave through the part wall to measure
thickness.
Sampling, cutting coupons, disassembly, or destroying
your part are no longer necessary.
And you can measure thickness anywhere on your part with
access to only one side.
|
|
Click to Download
:
WT-600Series Catalog
Click
to Download : WT-600Series
Probe Zero & Calibration
|
|
|
|
A Pulse/Echo ultrasonic thickness gauge
determines the thickness of a part or structure by accurately
measuring the time required for a short ultrasonic pulse
generated by a transducer to travel through the thickness
of the material, reflect from the back or inside surface
and be returned to the transducer.
|
WT-600 series,
digital ultrasonic thickness gauges are handheld, micro-processor
controlled instruments for measuring a wide variety of
fabricated parts, especially where conditions allow access
to one side only. Where you're spot checking thickness
of incoming material, performing quality control on finished
parts, or monitoring machining operations, the WT-600
series shorten inspection time and reduce costs.
|
WT-630 is the "Best"
choice ¡¦ to satisfy your thickness measurement needs
B-scan provides a graphical thickness cross-sectional
view of the work piece being inspected.
It is very helpful in quickly identifying laminated or
heavily thinned areas. Pit size and contour can be easily
mapped giving a representative view of the extent of corrosion
pit damage.
WT-630 for Accurate Data Collection and Simple Data Management
Using the on-board data logger makes collecting data with
the WT-630 an easy operation for on inspector.
In the Normal, Alarm Average and Differential mode, readings
are automatically stored in the
on-board data logger by pressing the MEM key.
A total 1,500 readings can be stored and divided into
50 data group in the WT-630's data logger memory.
Helios 2000 is an intuitive Microsoft Windows 95/98/ME/2000
thickness data control program that simplifies the transfer,
storage, analysis and documentation of thickness data.
|
Alarm Mode
|
If the measurement falls below your
minimum specified value or is over your maximum
specified value, the red LED will light and the
beeper will sound. The green LED will light to indicate
an acceptable thickness. |
Average Mode
|
If you intend to know the uniformity
of certain area, you can use this function. The
unit will calculate the average value of 4 times
measured data automatically. |
Differential Mode
|
The unit will display the positive
or negative difference of your minimum specified
value. |
High Speed Scan Mode
|
By dragging the probe along any given
area, the unit will display the thinnes reading
it found at a rate of 20 readings per second. |
Statistics Data Mode
|
The unit will display velocity,
minimum, maximum and average value of measured data. |
Easy to Use
|
Installation of Helios 2000 is easy
through the automated installation program. |
Direct WT-630 Communication
|
Simple, fast, bi-directional communication
(send/receive) is provided with the model WT-630
B-Scan thickness gauge. |
Copy and Paste
|
Provides a quick and easy way to get
inspection data into standard spreadsheet (MS-Excel)
program.Print report through all Microsoft Windows
95/98/Me/2000 supported printers. (Windows NT not
support) |
Real-time Trigger Function
|
WT-630 B-scan thickness gauge will transfer
real-time
B-scan thickness data to PC directly. |
|
|
|
|
|
